Extract Classification:
Features: Modern Design, Double Low-E Glass, Sound Insulation, Thermal Break
Service: None specified in title text.
Application: Hotels, Interior
Product Description:
Sunshine presents the Bay and Bow Window. It uses a high-precision 6063-T5 aluminum profile. The main material wall thickness is ≥1.4mm. An insulation strip of 25.3mm provides thermal efficiency. This unit features an internal opening and an internal inverted design. The frame uses a hidden anti-backflow drainage system. Rounded corners improve safety and appearance. Hardware options include Roto and Siegenia. Maximum load capacity reaches 80kg. Glass options include 5mm+19A+5mm for insulation. Surface treatment uses a durable fluorocarbon triple coating.
Parameter Value
Material: Aluminium Alloy (6063-T5)
Profile Thickness: Main material wall thickness ≥ 1.4mm
Frame Visible Surface: Indoor: 26.5mm; Outdoor: 63mm
Insulation Strip Width: 25.3mm
Glass Channel Width: Frame: 39mm; Fan: 34mm
Standard Glass: 5mm+19A+5mm (Fixed and Fan)
Hardware Brands: Roto, Hopo (Standard); Siegenia (Upgrade)
Max Load Capacity: 80kg
Max Opening Angle: 100 degrees / 180 degrees
Surface Treatment: Fluorocarbon Triple Coating
Certifications: FSC, CE, ISO 9001, SGS
Warranty: Over 5 years
Product Features
Isotherm Structure: Uses a 25.3mm insulation strip. It reduces heat transfer effectively.
High Load Capacity: Supports up to 80kg. Fits fan widths up to 2700mm.
Hidden Drainage System: Features anti-backflow drainage. It prevents water ingress and corrosion.
Enhanced Safety: Includes a rounded corner design. It improves safety during daily use.
Versatile Hardware Options: Equipped with Roto or Hopo handles. Upgrades to Siegenia are available.
Application Scenarios
Hotels: Provide quiet rooms with effective sound insulation.
Villas & Homes: Offers modern design and thermal comfort.
Offices: Reduce external noise for focused work.
Exterior Use: Features durable surface treatment for weather resistance.
Bedrooms & Living Areas: Ensures privacy and temperature control.
FAQ
Q: What materials are used for this window?
A: We use 6063-T5 aluminum alloy with a wall thickness of ≥1.4mm. It includes a 25.3mm insulation strip and fluorocarbon triple coating.
Q: What is the maximum size and load capacity?
A: The maximum fan width reaches 2700mm. The load capacity is 80kg. Opening angles range from 0 to 180 degrees.
Q: What hardware brands are available?
A: Standard hardware includes Roto and Hopo. Upgraded options include Siegenia. A 3-point lock is recommended for high-rise buildings.
Q: How does the drainage system work?
A: It uses a hidden anti-backflow design. This prevents water from entering the frame.
Q: What is the warranty period?
A: The warranty period is over 5 years. Products are certified by CE, ISO 9001, and SGS.
